Functional description of STM32H743I-EVAL, STM32H747I-EVAL and STM32H747I-DISCO
50/76 UM2222 Rev 2
Note: The BMP files used with this module need to be stored in the SD card or USB storage and
under “BMP” folder.
8.1.6 Dual core module
Overview
The dual core module demonstrates the platforms dual core capability while decoding four
video files and rendering fractal bitmap.
Checking the check box offloads the fractal rendering on the second core (CM4). This
should decrease the CM7 core loading.
Figure 37. Dual core module
8.1.7 System information
Overview
The system information shows the main demonstration information, such as the used board,
the STM32H7 part number, the current CPU clock and the demonstration revision.
Figure 38. System information main screen
