ST STM32F7 Series - Figure 3. VDDSDMMC Connected to External Power Supply; Figure 7. Stm32 F7 X2 Xx Power Supply Scheme; Figure 8. Stm32 F7 X3 Xx Power Supply Scheme

DocID027559 Rev 5 53/54
AN4661 Revision history
53
09-May-2016 4
Updated Table 1: Regulator ON/OFF and internal reset ON/OFF
availability adding the WLCSP180 package and notes.
Added Figure 3: VDDSDMMC connected to external power supply.
Updated Section 1.1.4: Independent DSI supply for
STM32F769xx/STM32F779xx devices: V
SSDSI
pin must be
grounded.
Added Section 6.7: Recommendations for the WLCSP180 package
in the STM32F769Ax/STM32F768Ax devices.
03-Feb-2017 5
Updated Section 1.1.2: Independent USB transceivers supply.
Updated Section 1.2: Power supply scheme.
Added Figure 7: STM32F7x2xx power supply scheme.
Added Figure 8: STM32F7x3xx power supply scheme.
Updated Table 1: Regulator ON/OFF and internal reset ON/OFF
availability adding the LQFP64 and WLCSP100 packages and notes.
Updated Table 3: STM32F7 Series bootloader communication
peripherals adding peripherals.
Table 11. Document revision history (continued)
Date Revision Changes
