28.6.10 TIMx capture/compare mode register 2 [alternate]
(TIMx_CCMR2)(x = 1, 8, 20)
Address offset: 0x01C
Reset value: 0x0000 0000
The same register can be used for output compare mode (this section) or for input capture
mode (previous section). The direction of a channel is defined by configuring the
corresponding CCxS bits. All the other bits of this register have a different function for input
capture and for output compare modes. It is possible to combine both modes independently
(e.g. channel 3 in input capture mode and channel 4 in output compare mode).
Output compare mode
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:12 IC4F[3:0]: Input capture 4 filter
Bits 11:10 IC4PSC[1:0]: Input capture 4 prescaler
Bits 9:8 CC4S[1:0]: Capture/compare 4 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC4 channel is configured as output
01: CC4 channel is configured as input, tim_ic4 is mapped on tim_ti4
10: CC4 channel is configured as input, tim_ic4 is mapped on tim_ti3
11: CC4 channel is configured as input, tim_ic4 is mapped on tim_trc. This mode is working
only if an internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC4S bits are writable only when the channel is OFF (CC4E = ‘0’ in TIMx_CCER).
Bits 7:4 IC3F[3:0]: Input capture 3 filter
Bits 3:2 IC3PSC[1:0]: Input capture 3 prescaler
Bits 1:0 CC3S[1:0]: Capture/compare 3 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC3 channel is configured as output
01: CC3 channel is configured as input, tim_ic3 is mapped on tim_ti3
10: CC3 channel is configured as input, tim_ic3 is mapped on tim_ti4
11: CC3 channel is configured as input, tim_ic3 is mapped on tim_trc. This mode is working
only if an internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC3S bits are writable only when the channel is OFF (CC3E = ‘0’ in TIMx_CCER).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. OC4M[3] Res. Res. Res. Res. Res. Res. Res. OC3M[3]
rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OC4
CE
OC4M[2:0]
OC4
PE
OC4
FE
CC4S[1:0]
OC3
CE
OC3M[2:0]
OC3
PE
OC3
FE
CC3S[1:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:25 Reserved, must be kept at reset value.
Bits 23:17 Reserved, must be kept at reset value.
Bit 15 OC4CE: Output compare 4 clear enable
