Direct memory access controller (DMA) RM0440
416/2126 RM0440 Rev 4
12.6.2 DMA interrupt flag clear register (DMA_IFCR)
Address offset: 0x04
Reset value: 0x0000 0000
Setting the global clear bit CGIFx of the channel x in this DMA_IFCR register, causes the
DMA hardware to clear the corresponding GIFx bit and any individual flag among TEIFx,
HTIFx, TCIFx, in the DMA_ISR register.
Setting any individual clear bit among CTEIFx, CHTIFx, CTCIFx in this DMA_IFCR register,
causes the DMA hardware to clear the corresponding individual flag and the global flag
GIFx in the DMA_ISR register, provided that none of the two other individual flags is set.
Writing 0 into any flag clear bit has no effect.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
CTEIF8
CHTIF8 CTCIF8
CGIF8
CTEIF7
CHTIF7 CTCIF7
CGIF7
CTEIF6
CHTIF6 CTCIF6
CGIF6
CTEIF5
CHTIF5 CTCIF5
CGIF5
wwwwww w w w w w w w w w w
1514131211109876543210
CTEIF4
CHTIF4 CTCIF4
CGIF4
CTEIF3
CHTIF3 CTCIF3
CGIF3
CTEIF2
CHTIF2 CTCIF2
CGIF2
CTEIF1
CHTIF1 CTCIF1
CGIF1
wwwwww w w w w w w w w w w
Bit 31 CTEIF8: transfer error flag clear for channel 8
Bit 30 CHTIF8: half transfer flag clear for channel 8
Bit 29 CTCIF8: transfer complete flag clear for channel 8
Bit 28 CGIF8: global interrupt flag clear for channel 8
Bit 27 CTEIF7: transfer error flag clear for channel 7
Bit 26 CHTIF7: half transfer flag clear for channel 7
Bit 25 CTCIF7: transfer complete flag clear for channel 7
Bit 24 CGIF7: global interrupt flag clear for channel 7
Bit 23 CTEIF6: transfer error flag clear for channel 6
Bit 22 CHTIF6: half transfer flag clear for channel 6
Bit 21 CTCIF6: transfer complete flag clear for channel 6
Bit 20 CGIF6: global interrupt flag clear for channel 6
Bit 19 CTEIF5: transfer error flag clear for channel 5
Bit 18 CHTIF5: half transfer flag clear for channel 5
Bit 17 CTCIF5: transfer complete flag clear for channel 5
Bit 16 CGIF5: global interrupt flag clear for channel 5
Bit 15 CTEIF4: transfer error flag clear for channel 4
Bit 14 CHTIF4: half transfer flag clear for channel 4
Bit 13 CTCIF4: transfer complete flag clear for channel 4
Bit 12 CGIF4: global interrupt flag clear for channel 4
