Operational amplifiers (OPAMP) RM0440
826/2126 RM0440 Rev 4
25.5.12 OPAMP6 timer controlled mode register (OPAMPx_TCMR) (x = 1...6)
Address offset: 0x2C
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
LOCK Res.
rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res.
T20CM
_EN
T8CM_
EN
T1CM_
EN
VPS_SEL
VMS_
SEL
rw rw rw rw rw rw
Bit 31 LOCK: OPAMP6_TCMR lock
This bit is write-once. It is set by software. It can only be cleared by a system reset.
This bit is used to configure the OPAMP6_TCMR register as read-only.
0: OPAMP6_TCMR is read-write
1: OPAMP6_TCMR is read-only
Bits 30:6 Reserved, must be kept at reset value.
Bit 5 T20CM_EN: TIM20 controlled mux mode enable
This bit is set and cleared by software. It is used to control automatically the switch between the
default selection (VP_SEL and VM_SEL) and the secondary selection (VPS_SEL and
VMS_SEL) of the inverting and non inverting inputs. This automatic switch is triggered by the
TIM20 CC6 output arriving on the OPAMP6 input multiplexers.
0: Automatic switch is disabled.
1: Automatic switch is enabled.
Bit 4 T8CM_EN: TIM8 controlled mux mode enable
This bit is set and cleared by software. It is used to control automatically the switch between the
default selection (VP_SEL and VM_SEL) and the secondary selection (VPS_SEL and
VMS_SEL) of the inverting and non inverting inputs. This automatic switch is triggered by the
TIM8 CC6 output arriving on the OPAMP6 input multiplexers.
0: Automatic switch is disabled.
1: Automatic switch is enabled.
