4.2.1 MPU access permission attributes
This section describes the MPU access permission attributes. The access permission bits,
TEX, C, B, S, AP, and XN, of the MPU_RASR register, control access to the corresponding
memory region. If an access is made to an area of memory without the required
permissions, then the MPU generates a permission fault.
Table 39 shows the encodings for the TEX, C, B, and S access permission bits.
Table 40 shows the cache policy for memory attribute encodings with a TEX value is in the
range 4-7.
Table 39. TEX, C, B, and S encoding
TEX C B S Memory type Shareability Other attributes
b000
0
0x
(1)
1. THe MPU ignores the value fo this bit.
Strongly-ordered Shareable -
1 x
(1)
Device Shareable -
1
0
0
Normal
Not shareable
Outer and inner write-through. No
write allocate.
1 Shareable
1
0
Normal
Not shareable
Outer and inner write-back. No write
allocate.
1 Shareable
b001
0
00
Normal
Not shareable
Outer and inner noncacheable.
- 1 Shareable
1 x
(1)
Reserved encoding -
1
0 x
(1)
Implementation defined attributes. -
1
0
Normal
Not shareable
Outer and inner write-back. Write
and read allocate.
1 Shareable
b010
0
0 x
(1)
Device Not shareable Nonshared Device.
1 x
(1)
Reserved encoding -
1x
(1)
x
(1)
Reserved encoding -
b1BB A A
0
Normal
Not shareable
Cached memory
(2)
, BB = outer
policy, AA = inner policy.
2. See Table 40 for the encoding of the AA and BB bits.
1 Shareable
Table 40. Cache policy for memory attribute encoding
Encoding, AA or BB Corresponding cache policy
00 Non-cacheable
01 Write back, write and read allocate
10 Write through, no write allocate
11 Write back, no write allocate
