PM0214 Rev 9 257/262
PM0214 Core peripherals
261
4.6.5 Floating-point default status control register (FPDSCR)
Address offset: 0x0C
Reset value: 0x0000000
Required privilege: Privileged
The FPDSCR register holds the default values for the floating-point status control data.
4.6.6 Enabling the FPU
The FPU is disabled from reset. You must enable it before you can use any floating-point
instructions.
The example shows an example code sequence for enabling the FPU in both privileged and
user modes. The processor must be in privileged mode to read from and write to the
CPACR.
Example
; CPACR is located at address 0xE000ED88
LDR.W R0, =0xE000ED88
; Read CPACR
LDR R1, [R0]
; Set bits 20-23 to enable CP10 and CP11 coprocessors
ORR R1, R1, #(0xF << 20)
; Write back the modified value to the CPACR
STR R1, [R0]; wait for store to complete
DSB
;reset pipeline now the FPU is enabled
ISB
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
AHP DN FZ RMode
Reserved
rw rw rw rw rw
1514131211109876543210
Reserved
Bits 31:27 Reserved, must be kept cleared.
Bit 26 AHP: Default value for FPSCR.AHP
Bit 25 DN: Default value for FPSCR.DN
Bit 24 FZ: Default value for FPSCR.FZ
Bits 23:22 RMode: Default value for FPSCR.RMode
Bits 21:0 Reserved, must be kept cleared.
