4.5.6 SysTick register map

The table provided shows the SysTick register map and reset values. The base address of

the SysTick register block is 0xE000 E010.

Table 55. SysTick register map and reset values

Offset Register

0x00

STK_CTRL

Reserved

COUNTFLAG

Reserved

CLKSOURCE

TICK INT

EN ABLE

Reset Value 0 1 0 0

0x04

STK_LOAD

Reserved

RELOAD[23:0]

Reset Value 000000000000000000000000

0x08

STK_VAL

Reserved

CURRENT[23:0]

Reset Value 000000000000000000000000

0x0C

STK_CALIB

Reserved

TENMS[23:0]

Reset Value 000000000000000000000000
