11-5
2 Raising the cab
CAUTION
Raise the cab slowly and gradually. Raising it
quickly and using too much force could damage
the cab tilt mechanism.
1. Pull out the primary release (lever A) . While
holding lever A, lift the secondary release (lever
B) .
2. Grasp the tilt grip and pull the safety release
(lever C) . The cab will rise slightly.
3. Use the tilt grip to raise the cab. After confirming
that the lock lever is hooked onto the cab stay
and the stay is secured, fit the hold-down
into the notch in the lock lever. The cab stay
must be completely straight for the hold-down to
engage in the notch.
WARNING
Be sure to fit the hold-down into the notch in
the lock lever to prevent the cab from drop-
ping, which could cause a personal injury.
Z10672
Z10673
Z14920
