12-17
6. Remove the screw at the bottom of the reflec-
tor , then pull the reflector away from the vehi-
cle as shown in the illustration.
7. Remove the headlight bolts and connectors
.
CAUTION
• Do not turn the beam adjusting screw .
Turning the beam adjusting screw would
change the beam setting, and could impair
visibility for drivers of other vehicles. If you
accidentally turn the beam adjusting screw,
have an authorized Sterling service facility
adjust the headlights.
• When setting down the removed headlight,
place it on a soft cloth to avoid scratching
the lens.
8. Raise the headlight slightly to remove the tabs
from the slots , then pull it out toward you.
Z11268
Z11269
Z11270
Z11271
