12-18 In an emergency
• Install the headlight.
1. Insert the tabs on the headlight into the
slots , and position the headlight properly.
2. Install the headlight bolts and connector .
3. Pull out the reflector keeper screw until it is
fully extended.
4. Insert the stud on the reflector into the
grommet , fit the reflector in place, and tighten
the bottom screw until firm.
CAUTION
Do not tighten the bottom screw too much. This
could damage the mounting.
5. Install the connector on the front and side turn
signal lens .
6. Pull out the two turn signal keeper screws .
until they are fully extended.
7. Align the tabs with their slots , and press
the front and side turn signal lens inward, toward
the centerline of the vehicle.
Z11272
Z11625
Z11273
Z11274
To Next Page
