FS 94 R
English
36
Definitions
1 Drive Tube
Encloses and protects the drive
shaft between the coupling sleeve
and gearbox.
2 Mowing Head
The cutting attachment, i.e. mowing
head, for different purposes.
3 Deflector for Mowing Heads only
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the cutting attachment and from
contact with the cutting attachment.
4 Line Limiting Blade
Metal blade at the deflector in order
to keep the line of the mowing head
at the proper length.
5 Deflector for all Mowing Tools
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the cutting attachment and from
contact with the cutting attachment.
6 Skirt for Mowing Heads
Extension attached to the bottom of
the deflector when using mowing
heads.
7 Metal Cutting Attachment
The cutting attachment, i.e. blade,
made from metal for different
purposes.
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
Engine
Single cylinder two-stroke engine
Ignition System
Electronic magneto ignition
This spark ignition system meets all
requirements of the Canadian
Interference-Causing Equipment
Standard CAN ICES-2/NMB-2.
Fuel System
All position rotary valve carburetor with
integral fuel pump
Weight
Overall length
Features
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Displacement: 24.1 cc
Bore: 35 mm
Stroke: 25 mm
Engine power to
ISO 8893:
0.9 kW (1.2 bhp)
at 8,000 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 9,800 rpm
Max. output shaft
speed (cutting
attachment): 7,290 rpm
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.5 mm
Fuel tank capacity: 540 cc (0.54 l)
Dry, without cutting attachment and
deflector
FS 94 R: 4.6 kg
without cutting
attachment 1780 mm
R Loop handle
Z Spark arresting screen
