Stihl FS 94 R User Manual

FS 94 R
English
24
Using Transport Guard
The type of transport guard depends on
the metal cutting attachment supplied
with the machine. Transport guards are
available as special accessories.
230 mm grass cutting blades
Grass Cutting Blades up to 260 mm
N Disconnect wire rod from the
transport guard.
N Swing wire rod outwards.
N Fit the transport guard on the cutting
attachment from below.
N Hook wire rod to the transport
guard.
N Swing wire rod into position.
Transporting the Unit
681BA268 KN
681BA269 KN
681BA270 KN
681BA301 KN
681BA275 KN
1.
2.
681BA305 KN
2.
681BA311 KN

Stihl FS 94 R Specifications

General

Engine Displacement	24.1 cc
Engine Power	0.9 kW (1.2 bhp)
Cutting Diameter	420 mm (16.5 in)
Weight	4.9 kg
Fuel Capacity	540 cc (18.3 oz)
Vibration Level	3.5 m/s²
