Assembly and setting up 4
Checking safety equipment 4.7
4-21
Safety device Checking
Production setting
Pull engaging rod to highest position and
release. The carriage pulls out.
The engaging rod is held by a magnet.
Press engaging rod to bottom position (zero
position).
The carriage must be stopped immediately
Middle position
Engaging rod (1)
Pull engaging rod to middle position and
release. The carriage pulls out.
The engaging rod is not held by a magnet,
must rather fall back to the zero position.
The carriage must be stopped immediately
Cover hood (2)
Pull engaging rod to highest position and
release.
The carriage pulls out.
Open shrouding cover
The carriage must be stopped immediately
The engaging rod falls to zero position
simultaneously.
Repeat this process for each shrouding cover
Side protective hoods
(3)
Pull engaging rod to highest position and
release.
The carriage pulls out.
Open the protective hood on the right side of
the machine.
The carriage must be stopped immediately
The engaging rod falls to zero position
simultaneously.
Repeat this process for the protective hood on
the left side of the machine.
Main switch, (4)
Emergency stop
switch
Pull engaging rod to highest position and
release.
The carriage pulls out.
Switch off main switch / emergency shutdown
switch (position "OFF")
The carriage must be stopped immediately
The engaging rod falls to zero position
simultaneously.
The machine must switch off automatically
