4 Assembly and setting up
4.7 Checking safety equipment
4-22
Drive limit switch
Call up the "Reference runs" window
from the main menu and tap the "S<" key.
Pull engaging rod to highest position.
The carriage moves towards left.
The machine must stop shortly before
reaching the buffer. The limit switch triggers
the stop signal.
Push carriage from limit switch manually.
To confirm the calibration, tap the
key.
Repeat the check on the right side of the
machine, in that call up the window
"Reference runs" in the main menu
and tap the "S<" key.
Cover (5)at take-down
comb
Pull engaging rod to highest position and
release.
The carriage pulls out.
Push cover to the left. A moulded handle is
located on the right-hand side of the cover.
Caution Caution: The cover is tilted a little
outwards.
The carriage must be stopped immediately
The Touch-Screen displays am error
message.
Close the cover again.
To confirm the calibration, tap the
key.
Cover (5)at take-down
comb
(light barrier)
Pull engaging rod to highest position and
release.
The carriage pulls out.
Push the cover lightly toward the rear.
The carriage must be stopped immediately
The Touch-Screen displays am error
message.
To confirm the calibration, tap the key.
