R2W PLUS
49
4.5 Coordinate Measurement Mode
4.5.1 Setting coordinate of occupied point
After input coordinate of occupied point (instrument location), unknown point coordinate
will be measured and displayed with this program.
Operation steps
Keys
Display
①Click “M.Coor” key to
enter coordinate
measurement mode.
【M.Coor】
②Click “OCC PT” key.
【OCC PT】
