STONEX R2W PLUS 500 - Page 60

R2W PLUS
51
②Input coordinate of
backsight point and click
“Enter” key.
【Enter】
③A dialog box is ejected as
figure shows.
④Collimate backsight point,
click “Yes” key. And then
the system will define
backsight azimuth angle
which displays in the upper
left corner of coordinate
measurement screen.
【Yes】
