R2W PLUS
61
●When measuring coordinate of ground point A1, set instrument height and prism height.
●When measuring coordinate of point A0, set instrument height only (Prism height is set
as 0).
●Refer to “4.5.1” to set coordinate of occupied point.
Operation steps
Keys
Display
①
Click “DIST Offset” key in
ejecting dialog box.
【DIST
Offset】
②Finish data entry with
stylus.
③Collimate prism and click
“Measure” key.
【Measure】
