Insight 3.7 Installation Guide page 5
____________________________________________________________________________________
Tip Offset Procedure
If you are installing a new FDM modeler or have recently changed the heads or tips, you will
want to perform tip offset calibration. Refer to the FDM manual for a more complete description
of the tip offset calibration procedure.
1. Check the tightness of the tip using the tip wrench.
2. Start FDM Status application.
3. Click the Calibration
button.
4. Specify the properties of the modeler in the Configure Modeler window. This is much like
the configuration window in Insight. Specify the
model material type
support material type
model tip size
support tip size
slice height
5. Click to confirm the modeler configuration parameters. These parameters will determine
the values used to build the calibration box used to set the tip offset values.
6. The Calibration window is displayed.
