English
2.6 Installing the batteries
Fig.5
Open the cover on the remote control and insert 2x AAA type batteries into the compartment.
Observe correct polarity of the batteries when inserting. A terminal diagram is shown inside the
compartment.
1. Remove the cover. 2. Insert the batteries. 3. Place the cover.
2.7 Using the remote control
Fig.6
To use the remote control, point it towards the front of your receiver. The remote control supports a
range of up to 5 meters distance to the receiver at an angle of up to approx. 30 degrees.
NOTE: Managing the receiver will be limited or not possible if there are obstacles
between the remote control sensor (at the front panel of the receiver)
and the remote control. Direct sunlight or very bright light can reduce or
disturb the reception of the remote control signals.
3.0 CONNECTION
3.1 Connecting to a terrestrial antenna
Fig.7
To receive broadcast signal, your terrestrial indoor or outdoor antenna must be connected to the
ANT IN connector on the back of the receiver. Use a properly shielded antenna cable and suitable
connectors.
3.2 Connecting to TV with HDMI cable
Fig.7
The TV set shall be connected with the receiver using a good quality HDMI 1.3 or higher cable. This
connection gives the highest possible quality.
3.3 Connecting to TV with SCART cable
Fig.7
The unit is also equipped with a SCART connector; alternatively, the TV set can be connected to the
receiver using a good quality SCART cable.
3.4 Connecting to a Digital Audio Amplier with S/PDIF
Fig.8
By connecting your receiver to a digital amplier or home theatre system, you can enjoy the best
possible sound quality and multi-channel audio (depending on broadcast) up to Dolby Digital.
Connect your Digital Audio Amplier or home theatre system with a suitable cinch cable to the S/
PDIF connector on the back of the receiver.
7
