Struers AbraPol-10 - Technical Data

AbraPol-10
Instruction Manual
60
5. Technical Data
Subject Specifications
Metric/International
US
Rotational speed 150/300 rpm 150/300 rpm
Size 300/350 mm 11.8”/13.7”
Disc
Power Consumption 1.5 kW 2 Hp
Speed 166/333 rpm
Direction CW/CCW
Force 0-700 N 0-150 lbf
Specimens
Motor power consumption 0.37 kW 0.5 Hp
Level 0-20 Dosing Unit
No. of pumps 3
Power supply 3 (3L+PE)
Power Consumption 140 W 0.2 Hp
Width 500 mm
Depth 400 mm
Height 410 mm
Cooling water
Recirculation
Cooling Unit
Weight 7.2 kg
LC Display 240x128 pixels
Controls Touch pads/Push-turn knob
Software and
electronics
Memory EPROM/RAM/NV-RAM
Environment Safety standards 98/37/EØF
EN292-1:1991; EN292-2:1991+A1;
EN418:1992; EN574:1996;
EN953:1997; EN954-1:1997;
EN1050:1997;
NFPA70:1996; UL508; NFPA79:1997
FCC part15, subpart
EMC EN50081-1:1992; EN50082-1:1997
Noise level(idle 300/300) 77 dbA
Surrounding temperatur 5-40°C
Humidity Max. 95%RH
