English
Operation Guide
OPERATING THE OPTIONAL CRANK FOWLER/OPTIONAL CRANK GATCH
The fowler and gatch crank handles are stored under the litter and held out of the way with magnets. Pivot the crank
out and push in to engage it.
To raise the fowler, turn the crank handle (A) clockwise.
To lower the fowler, turn the crank handle (A) counterclockwise.
To raise the gatch, turn the crank handle (B) clockwise.
To lower the gatch, turn the crank handle (B) counterclockwise.
Note: The stretcher may have a stationary foot end instead of a gatch.
Figure 7: Fowler and Gatch Crank Handles
A
B
