Preventative Maintenance
LUBRICATION POINTS
Crank Screw Assembly (1069-042-110)
With the fowler at 0 degrees, apply Syntech grease (3000-200-719) through the slot and hole in the crank screw
assembly (as shown below). Wipe off excess grease.
