OPTIONAL PositionPRO™ PATIENT REPOSITIONING MATTRESS OPTION (CONTINUED)
CAUTION
Gently lower the foot end section to not damage the control box.
12. Fasten the retaining straps to secure the mattress to the bed frame (four (4) straps total).
13. Connect the power cord to the 110V outlet on the bed.
Applying the linens
1. Apply the linens using the “D” rings for the flat sheet.
2. To effectively use the “Turn Assist”, do not pull linens taut. Linens should remain loose and wrinkly on surface of
the mattress.
WARNING
Ensure that you have always access to the CPR straps.
OPTIONAL ZOOM
®
DRIVE SYSTEM (MODEL 2141 ONLY)
If your bed is equipped with the Optional ZOOM
®
Drive System, run through the preceding setup procedures and
continue with the procedures listed below.
• With the battery power switch in the “ON” position and the drive wheel in the neutral position (not touching the
floor), ensure the “Engage Drive Wheel” LED on the head end control panel is illuminated.
• Run through the operation of the drive wheel (refer to page 59) to ensure it is operating properly.
• On both sides of the bed, flip the manual backup brake pedal outward and depress down fully on the head side of
the pedal. The letter D in GREEN should be visible in the clear window located on the base next to the pedal. The
ZOOM® drive (2141 Model only) should now be engaged. Depress down fully on the center of the pedal until the
letter N in BLUE is visible in the clear window. The ZOOM
®
drive should now be disengaged.
