Pendant with Motion Control/NC/Smart TV - FA64193
Note: Illustration may differ according to bed model.
A
Insert the removable pendant
in in this space. Slide it until it
clips.
The Optional Pendant with Motion Control, Nurse Call and Smart TV was designed to give the patient control over
the bed’s motions, TV, radio, channels, volume and lights as well as being able to contact a nurse from the bed when
needed.
The bed must be configured and synchronized with the hospital system in order for some functions to operate properly
such as Nurse Call, TV control, radio, channels, volume and lights.
WARNING
The Weigh system as well as the Bed Exit system must be adjusted if this accessory is added when either system is
in function. Refer to the “Add/Remove Equipment” from the bed procedure on page 35.
INSTALLATION
Required Tools: None
1. Plug the cable connector into connector (A) located on the right of the upper frame.
2. Install the removable pendant on the right foot siderail.
Motion Control
Smart TV
Nurse Call
