MAIN MENU: iBED (CONTINUED)
iBed, Head of Bed (HOB) History
When the “HOB History” button is pressed on the
iBed screen, Figure 10.9a will be displayed.
The “Head of Bed History” displays the head’s
angle of the bed for the last 24 hours.
When the “Angle History” button is pressed on the
Head of Bed screen, Figure 10.9b will be displayed.
iBed, Bed Height History
When the “Bed Height History” button is pressed on
the iBed screen, Figure 10.10a will be displayed.
When the “Height History” button is pressed on the
Bed Height screen, Figure 10.10b will be displayed.
The “Bed Height History” provides the user with
information on the current bed height as well as
the bed height for the last 24 hours. If the Bed
Height History needs to be reset, press the “Reset”
button.
Footboard Operation Guide
Figure 10.9a
Figure 10.9b
Head of Bed
Close
Jul. 22, 2003 09:22 AM
Angle
Duration
20°
02h24min
Angle
History
Angle History
Close
Reset
HOB 30
History
Angle Last 12h Last 24h
0 ~ 9° 12:00 24:00
10 ~ 19° 12:00 24:00
20 ~ 29° 12:00 24:00
30 ~ 39° 12:00 24:00
40 ~ 49° 12:00 24:00
50 ~ 59° 12:00 24:00
60 ~ 69° 12:00 24:00
70 ~ 79° 12:00 24:00
80 ~ 89° 12:00 24:00
Figure 10.10a
Bed Height
Close
Jul. 22, 2003 09:22 AM
Height
Duration
28 in
02h24min
Height
history
Figure 10.10b
Height history
Close
Reset
Low height
History
Height Last 12h Last 24h
16 ~ 18
18 ~ 20
20 ~ 22
22 ~ 24
24 ~ 26
26 ~ 28
28 ~ 30
30 ~ 33
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
