Footboard Operation Guide
Height history
Close
Reset
Low height
History
Height Last 12h Last 24h
16 ~ 18
18 ~ 20
20 ~ 22
22 ~ 24
24 ~ 26
26 ~ 28
28 ~ 30
30 ~ 33
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
00:00 00:00
Figure 8.8
Figure 8.9
Bed Height
Close
Jul. 22, 2003 09:22 AM
Height
Duration
28 in
02h24min
Height
history
When the “Bed Height” button is pressed on the
History screen, Figure 8.8 will be displayed.
When the “Height history” button is pressed on the
Bed Height screen, Figure 8.9 will be displayed.
The “Bed Height History” provides the user with
information on the current bed height as well as
the bed height for the last 24 hours. If the Bed
Height History needs to be reset, press the “Reset”
button.
Nurse Control Backlight Button
MAIN MENU: OPTIONS (CONTINUED)
