Permanent I.V. Pole (Continued) - FA64221
OPERATION
1. Lift and pivot the pole from the storage position and push down until it is locked into the receptacle.
2. To raise the height of the pole, pull up on the telescoping portion (A) until it locks into place
at its fully raised position. There are no intermediary positions for this section.
3. Rotate the I.V. pole hangers (B) to desired position and hang the I.V. bag.
4. To store the I.V. pole, turn the latch (C) clockwise until section (A) lowers. Lift up on
the pole to remove it from its receptacle, fold it and store it on the bracket.
CAUTION
The weight of the I.V. bags should not exceed 40 lbs (18 kg).
