Stryker Isolibrium 2971 Maintenance Manual

PPnneeuummaattiicc
Back/ Thigh
Section
Right
BR
Seat
Section
Right
SR
LEGEND
Exhaust line Pressure Line
ISOLIBRIUM PNEUMATIC DIAGRAM
Back/ Thigh
Section
Left
BL
Seat
Section
Left
SL
Turn
Right
Section
TR
Turn
Left
Section
TL
Valve Manifold
Quick
Disconnect
2971-022-162
VALVE, MB3E1
2971-022-162
VALVE, MB3E1
CPR/Relief
Valve
Quick
Disconnect
2971-022-162
VALVE, MB3E1
2971-022-162
VALVE, MB3E1
CPR/Relief
Valve
Quick
Disconnect
2971-022-163
VALVE, 310 SERIES, NC
CPR/Relief
Valve
2971-022-163
VALVE, 310 SERIES, NC
Quick
Disconnect
2971-022-162
VALVE, MB3E1
2971-022-162
VALVE, MB3E1
CPR/Relief
Valve
Quick
Disconnect
2971-022-162
VALVE, MB3E1
2971-022-162
VALVE, MB3E1
CPR/Relief
Valve
2971-022-164
VALVE, 310 SERIES, NO
Quick
Disconnect
2971-022-163
VALVE, 310 SERIES, NC
2971-022-163
VALVE, 310 SERIES, NC
CPR/Relief
Valve
2971-022-163
VALVE, 310 SERIES, NC
Air Intake/
Exhaust
Thomas
6025SE
24VDC
M
Pressure Sensor Board
EN 12 2971-009-002 Rev D.0
