CCaabbllee aanndd tteesstt ppooiinntt
((LLEEDD)) llooccaattiioonn
VVoollttaaggee PPoossiittiivvee lleeaadd NNeeggaattiivvee lleeaadd DDeessccrriippttiioonn
SRI (D25) +24VDC TP8 TP24 GND +24VDC from the
main board to
solenoid valve (Seat
Right Inflate)
SRD (D24) +24VDC TP15 TP24 GND +24VDC from the
main board to
solenoid valve (Seat
Right Deflate)
IN (D28) +24VDC TP10 TP24 GND +24VDC from the
main board to
solenoid valve (Air
Intake)
EX (D29) +24VDC TP17 TP24 GND +24VDC from the
main board to
solenoid valve (Air
Exhaust)
J14 +12VDC Pin 1 red Pin 6 black +12VDC out to sensor
board from main
board
J6 +24VDC Pin 1 yellow Pin 2 black +24VDC out to
compressor from the
main board (variable
voltage) - D65 =
24.4% - D66 = 48.8%
- D67 = 73.2% - D68 =
97.6% - D71 = 110%
2971-009-002 Rev D.0 17 EN
