Stryker M Series User Manual

www.stryker.com 1025-009-005 REV B 1-17
OPERATING THE OPTIONAL KNEE GATCH
To raise the knee gatch, pump handle (A) repeatedly to the left as shown in Figure 8.
To lower the knee gatch, pull out handle (B) as shown in Figure 8.
CAUTION
The weight capacity of the knee gatch is 200 pounds. Do not sit or stand on the gatch. Injury or damage to the equipment
could occur.
To prop the foot end of the knee gatch up, lift up the end of the knee gatch, allowing the prop rod to swing down and
engage in the bracket. To release the prop, lift up on the end of the gatch, swing the prop rod toward the head end of
the bed to disengage the bracket and lower the foot end. (See Figure 9)
A
B
Return To Table of Contents
Stretcher Operation
FOOT END
Figure 8 - Knee Gatch - Foot End
Figure 9 - Knee Gatch
