Stryker M Series User Manual

1-2 1025-009-005 REV B www.stryker.com
Introduction
Return To Table of Contents
INTENDED USE
This manual is designed to assist you with the maintenance of Stryker Model 1025 M-Series Stretcher with ZOOM
®
.
Carefully read this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe
operation of this equipment, it is recommended that methods and procedures be established for educating and training
staff on the safe operation of this stretcher.
PRODUCT DESCRIPTION
The Stryker Model 1025 M-Series Stretcher with ZOOM
®
product is a general purpose patient transport and treatment
stretcher.
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load
indicates the sum of the patient,
mattress, and accessory weight.
700 pounds 318 kg
Weight of Product
26” Stretcher
415 lbs (standard configuration)
465 lbs (all options/accessories)
188 kg
211 kg
30” Stretcher
435 lbs (standard configuration)
485 lbs (all options/accessories)
197 kg
220 kg
Overall Stretcher Length
85” (± .5”) 215.9 cm (± 1.27 cm)
Overall Stretcher Width (Siderails Up) 34.5” & 37” (± .5”) 87.6 cm & 93.98 cm (± 1.27 cm)
Overall Stretcher Width (Siderails Down) 26.5” & 30.75” (± .5”) 67.3 cm & 78.11 cm (± 1.27 cm)
Minimum / Maximum Stretcher Height 23” / 34” (± .5”) 58 cm / 86 cm (± 1.27 cm)
Fowler Angle 0° to 90° (± 3°)
Knee Gatch Angle 0° to 40° (± 1°)
Trendelenburg / Reverse Trendelenburg +15° to -15°
Electrical
115 VAC, 60 Hz, 3.0 Amp
Optional: 230 VAC, 50/60 Hz, 3.0 Amp
Battery Voltage 24 V, 31 Ah
Water Protection IPX5
Mode of Operation Continuous
Electromagnetic Compatibility: Product conforms to EN 60601-1-2:1993 - Class A
Ambient Temperature in Charge Mode Not to exceed 82.4°F 28°C

Stryker M Series Specifications

General

Brand	Stryker
Model	M Series
Category	Medical Equipment
Language	English
