Stryker Performance-PRO XT - Kickstand sub assembly - 6085-002-016

KKiicckkssttaanndd ssuubb aasssseemmbbllyy -- 66008855--000022--001166
Rev A (Reference only)
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0004-515-000 Button head cap screw 3
B 0004-636-000 Button head cap screw 1
C 0011-302-000 Plain washer 2
D 0016-131-000 Nylock hex nut 1
E 0021-180-000 Set screw 1
F 6085-002-003 Kickstand spring housing 1
G 6085-002-004 Kickstand bottom bracket 1
H 6085-002-006 Kick bolt 1
J 6085-002-007 Kick bolt head 1
K 6085-002-008 Kick tube 1
L 6085-002-009 Kick tube cap 2
M 6085-002-011 Rocker strut, left 1
N 6085-002-012 Rocker strut, right 1
P 6085-002-013 Kickstand spacer 1
R 6085-002-014 Kickstand torsion spring 1
6086-009-002 Rev AB.2 41 EN
