OOuutteerr rraaiill ssuubb aasssseemmbbllyy,, rriigghhtt
6086-001-025 Rev C (Reference only)
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0001-004-011 Flat head cap screw 2
C 0004-613-000 Socket head cap screw 4
D 0004-848-000 Button head cap screw 2
E 0016-028-000 Fiberlock hex nut 10
F 6085-001-029
Slide housing assembly, right
(page 52) 1
G 6500-001-098 Litter dead stop, internal 1
J 6500-001-114 Outer rail extrusion 1
M 6500-001-243 IV pole backer plate 1
N 6500-001-244 IV clip backer plate 1
P 6500-001-245 Sensor housing backer plate 2
R 6500-002-130 Litter support bracket 2
T 6500-002-131 Litter support bracket, inner 2
6086-009-002 Rev AB.2 49 EN
