pg 18
External Control
Configuring MultiSwitch Plus
Configure cloudburst and MultiSwitch Plus for remote access to three
additional presets�
1 Press and hold the cloudburst footswitch while connecting power to
the pedal� Hold for at least 2 seconds, until the LED stops blinking�
2 Turn the DECAY knob all the way counter-clockwise to set the MIDI
CHANNEL to Channel 1� The LED should be GREEN�
3 Turn the PREDELAY knob to select the following MIDI OUT option:
• Send MIDI CC and Other Data: GREEN
• Send Other Data: AMBER
4 Turn the MIX knob all the way clockwise to set the EXP/MIDI jack to
MIDI Mode� The LED should be BLUE�
5 Press the cloudburst footswitch to exit and store the MIDI CHANNEL,
the MIDI OUTPUT setting, and the EXP/MIDI Jack Mode�
6 Connect a TRS cable to cloudburst’s EXP/MIDI jack�
7 Press and hold the A footswitch on MultiSwitch Plus while connecting
the other end of the TRS cable to any one of the three jacks to set it to
Preset Mode�
