Mono In - Mono Out: To connect cloudburst in a mono signal chain, use
TS cables for both cloudburst’s IN and OUT� Set the I/O Selector switch
to mono�
Mono In - Stereo Out: To feed a mono signal into cloudburst, use a TS
cable to cloudburst’s IN� Connect a TRS + dual TS cable to cloudburst’s
OUT to route cloudburst’s stereo signal to a stereo pedal� Set the I/O
Selector switch to mono stereo�
Stereo In - Stereo Out: To connect cloudburst in a stereo signal chain,
use TRS + dual TS cables into both cloudburst’s IN and OUT� Set the I/O
Selector switch to stereo�
*NOTE: Alternatively, you can use a TRS - TRS cable when connecting a pedal
with a TRS stereo input (such as connecting to the TRS stereo input of an El
Capistan tape delay)�
