pg 7
Rear Panel I/O and Control (continued)
USBC
Computer connection for MIDI
I/O and firmware updates�
9VDC
Only use an adapter with the
following rating:
• 9VDC, center negative
• 250mA minimum
(Adapter sold separately�)
EXP/MIDI
Multifunction communication jack for external control of cloudburst’s
features and functions� Can be set to operate in one of the following
modes� (See “Configuring the EXP/MIDI Jack” on page 11 for details�)
Expression Pedal Mode (see page 13)�
Favorite Mode (see page 14)�
Freeze Mode (see page 16)�
Infinite Mode (see page 16)�
MIDI Mode (see “Configuring MultiSwitch Plus” on page 18 or
“Saving Presets in MIDI Mode” on page 25
)�
