pg 20
DIG - dual digital delay
Power Up Modes
Configuring the EXP/MIDI Jack
1 Press and hold the TAP footswitch while powering up DIG� Once both
LEDs flash, release the footswitch�
2 Turn the MIX (EXP/MIDI JACK) knob to select the function of the rear
panel’s EXP/MIDI jack� The ON LED will change color to indicate the
current status as you turn the knob�
• Expression Pedal mode: GREEN (default) - Allows continuous
control over any of the knobs in any direction with a standard TRS
expression pedal� (See page 22 for details�)
• Favorite mode: AMBER - Allows you to recall a Favorite setting
using a Strymon MiniSwitch� (See page 23 for details�)
• Tap mode: RED - Allows you to set the master delay time via tap
tempo using a Strymon MiniSwitch� (See page 25 for details�)
• MIDI mode: BLUE - Allows for the selection of three presets using
a Strymon MultiSwitch Plus� Full MIDI functionality is also avail-
able by sending MIDI Program Change messages via 1/4" TRS
MIDI connection using a Strymon Conduit or MIDI EXP cable� Up to
300 presets are available via MIDI� (See “Configuring MultiSwitch
Plus” on page 26 or
“Saving Presets in MIDI Mode” on page 33�)
