pg 26
DIG - dual digital delay
External Control
Configuring MultiSwitch Plus
Configure DIG and MultiSwitch Plus for remote access to three
additional presets�
1 Press and hold the TAP footswitch while connecting power to the
pedal� Hold until both LEDs stop blinking�
2 Turn the TIME knob all the way counter-clockwise to set the MIDI
channel to Channel 1� The TAP LED should be GREEN�
3 Turn the TONE knob to select any of the following MIDI OUT options
(both LEDs will show the following indicated colors):
• Send MIDI CC, PC, and Other Data: WHITE
• Send MIDI CC and Other Data: GREEN
• Send MIDI PC and Other Data: PURPLE
• Send Other Data: AMBER
4 Turn the MIX knob all the way clockwise to set the EXP/MIDI jack to
MIDI mode� The ON LED should be BLUE�
5 Press either footswitch to exit and store the MIDI channel, the MIDI
OUT setting, and the EXP/MIDI jack mode�
6 Connect a TRS cable to DIG’s EXP/MIDI jack�
7 Press and hold the A footswitch on MultiSwitch Plus while connecting
the other end of the TRS cable to any one of the three jacks to set it to
Preset mode�
