DIG - dual digital delay
Live Edit Controls Quick Reference
DIG provides a way to adjust several secondary functions that are avail-
able on several knobs (see “Live Edit Functions” on page 7) � Live
Edit functions are saved per preset�
1 Press and hold the ON footswitch until both LEDs blink to enter Live
Edit mode�
2 Release the footswitch and use the knobs as described below�
3 Press ON footswitch to store your setting and exit Live Edit mode�
DRY LEVEL
See page 7 for an
illustrated description�
Turn the MIX knob—both LEDs change color from
GREEN (no dry signal) to AMBER (unity gain with
input)� Turn to maximum knob position to BLUE
(Track Mix, the default, where wet/dry balance is
adjusted via MIX and MIX 2 knobs)
CONFIG (dual delay mode)
See page 9 for an
illustrated description�
Turn the MIX 2 knob—the ON LED changes color
from GREEN (left - Series, the default), to AMBER
(center - Ping Pong), to RED (right -Parallel)
SYNC/FREE MODE
See page 12 for an
illustrated description�
Turn the TIME 2 knob—both LEDs change color
from GREEN (Sync, the default) to RED (Free)
DELAY 1 SUBDIVISION
See page 13 for an
illustrated description�
Turn the TIME knob—the TAP LED changes color
from GREEN (left - Dotted Eighth note), to AMBER
(center - Quarter note, default), to RED (right - Half
note)
DELAY 2 REPEATS
See page 14 for an
illustrated description�
Turn the REPEATS knob clockwise from left—both
LEDs change smoothly from GREEN (single
repeat) to AMBER (maximum feedback)� Turn to
maximum knob position to RED (Track Repeats,
the default, where Delay 2 follows Delay 1 repeats)
MIDI CLOCK SYNC
See page 15 for an
illustrated description�
Set the TYPE switch to the 12 bit (down) or 24/96
(up) position—status is momentarily shown on
both LEDs:
• 12 bit position: OFF, RED (default)
• 24/96 position: ON, BLUE
MIDI EXPRESSION
See page 16 for an
illustrated description�
Set the MOD switch to the deep (down) or off (up)
position—status is momentarily shown on both
LEDs:
• deep position: OFF, RED
• off position: ON, BLUE (default)
