pg 6
DIG - dual digital delay
Rear Panel I/O and Control (cont.)
9VDC
Use the included power
supply or an adapter with the
following rating:
• 9VDC, center negative
• 300mA minimum
USB
Computer connection for MIDI
control as well as for perform-
ing firmware updates�
EXP / MIDI
Multifunction communication jack for external control of DIG’s features
and functions� Can be set to operate in one of the following modes� (See
“Configuring the EXP/MIDI Jack” on page 20 for details�)
Expression Pedal mode (see page 22)�
Favorite mode (see page 23)�
Tap mode (see page 25)�
MIDI mode (see “Configuring MultiSwitch Plus” on page 26 or
“Saving Presets in MIDI Mode” on page 33)�
