Power Up Modes
Bypass Mode for Mono I/O
With the rear I/O Mode Selector set to mono, the EC-1 pedal is set for
True Bypass as the default�* Setting EC-1 to Buffered Bypass Mode
preserves the high frequency response of your instrument’s signal
through your pedal chain and long cable runs�
*NOTE: Whenever the rear I/O Mode Selector set to mono stereo or
stereo, the bypass mode is automatically set to Buffered Bypass�
1 Press and hold the FOOTSWITCH for at least 2 seconds while powering
up EC-1� Once the LED flashes RED, release the footswitch�
TIME REC LEVEL MIX
TAPE AGE REPEATS MECHANICS
low high
med
hold (tap)
single head dTape echo
2 Toggle the REC LEVEL (BYPASS MODE) switch to choose between
True or Buffered Bypass Modes� The LED will change color to
indicate the current status as you toggle the switch�
• True Bypass: set the switch to the low (left) or med (middle)
position� The LED lights GREEN (default)�
• Buffered Bypass: set the switch to the high (right) position� The
LED lights RED�
3 Press the FOOTSWITCH to store the Bypass Mode and begin using EC-1�
NOTE: The Bypass Mode setting persists across power cycles�
