pg 24
External Control
Configuring EC-1 for MultiSwitch Plus
Configure EC-1 and a Strymon MultiSwitch Plus (sold separately) for
additional external control�
1 Press and hold the EC-1
FOOTSWITCH
while connecting power to the
pedal� Hold for at least 2 seconds, until the LED blinks RED�
2 Turn the TIME knob all the way counter-clockwise to set the MIDI
CHANNEL to Channel 1� The LED should be GREEN�
3 Turn the TAPE AGE knob to select either one of the following MIDI
OUT options:
• Send MIDI CC and Other Data: GREEN
• Send Other Data: AMBER
4 Turn the MIX knob all the way clockwise to set the EXP/MIDI jack to
MIDI Mode� The LED should be BLUE�
5 Press the EC-1
FOOTSWITCH
to exit and store these settings�
