pg 22
External Control
External Tap Mode Switch Setup
Connect a MiniSwitch or other external momentary footswitch with a
TRS cable to tap in a delay time� (As covered on page 5, you can also
use EC-1’s FOOTSWITCH for Onboard Tap Mode�) Additionally, when
configured for Tap Mode, pressing and holding the external switch will
perform Infinite Repeats�
NOTE: Your Strymon MiniSwitch’s internal jumper switch must be changed
from the factory-default FAV/BOOST to the TAP setting for External Tap Mode
functionality—see page 21�
1 Configure the EXP/MIDI jack for External Tap Mode� (See page 15
or more info�)
2 Connect an external switch with a TRS cable to the EXP/MIDI jack�
OR
3 Tap in a tempo in quarter notes to set the delay time� The EC-1 pedal’s
LED will flash to indicate the tempo� Maximum tap range is 1 second�
Or, press and hold the external switch for infinite delay repeats�
NOTE: External Tap Mode utilizes the current TAP DIVISION setting� To change
the TAP DIVISION setting, you must use the EC-1 pedal’s FOOTSWITCH to
enter Onboard Tap Mode� See page 5�
