Power Up Modes - Quick Reference
Global parameters and functions can be accessed via a power up
procedure� All power up functions persist through power cycles�
1 Press and hold the EC-1 FOOTSWITCH for at least 2 seconds
while powering up EC-1� Once the LED flashes RED, release the
FOOTSWITCH�
2 Adjust the desired functions with the controls noted below�
3 Press the FOOTSWITCH to store your changes and exit Power Up Mode�
POWER UP MODE OPTIONS
BYPASS MODE
FOR MONO I/O
See page 11
for an illustrated
description�
Set the REC LEVEL switch - status shown on the LED
• True Bypass: switch in the low (left) or mid (middle)
position - LED GREEN (default)
• Buffered Bypass: switch in the high (right) position
- LED RED
SPILLOVER MODE
See page 12
for an illustrated
description�
Turn the MECHANICS knob - status shown momentarily
on the LED
• Off: AMBER (default, minimum knob position)
• ON: PURPLE (maximum knob position)
DRY SIGNAL
See page 13
for an illustrated
description�
Turn the REPEATS knob - status shown momentarily on
the LED
• Digital: GREEN (default, minimum knob position)
• Analog: RED (50% knob position)
• Kill Dry: BLUE (maximum knob position)
LED BRIGHTNESS
See page 14
for an illustrated
description�
Press and hold the footswitch again and turn the
MECHANICS knob to adjust the brightness of the LED�
EXP/MIDI JACK
MODE
See page 15
for an illustrated
description�
Turn the MIX knob - status shown on the LED
• Expression: GREEN (default, minimum knob position)*
• Favorite: AMBER (11 o’clock knob position)
• Tap: RED (12 o’clock knob position)
• Infinite: PURPLE (2 o’clock knob position)
• MIDI: BLUE (maximum knob position)
*NOTE: Also see “Expression Pedal Setup” on page 18 to configure your
pedal functionality per preset�
