Live Edit Functions - Quick Reference
EC-1 provides a way to adjust two secondary functions (also, see “Live
Edit Functions” on page 9 )� These settings are saved per Favorite or
MIDI preset�
1 Press and hold the ON footswitch, and within one second turn the knob
for the desired Live Edit function while holding the footswitch� (If the
switch is held for longer than one second without turning a knob, the
pedal will enter TAP mode�)
2 Release the footswitch once you’ve made your selection to return to
using EC-1�
FUNCTION DESCRIPTION
PREAMP
SELECT
See page 9
for an illustrated
description�
Turn the REPEATS knob to select the desired Preamp option -
status shown momentarily on the LED:
• Off: RED preamp is bypassed�
• Modded Tube Preamp: AMBER (default) enables the
modified tube preamp circuit (the default setting)�
• Original Tube Preamp: GREEN enables the original
tube preamp circuit
NOTE: See the following Preamp Boost function to
adjustment of the tube preamp’s level�
PREAMP
BOOST
See page 10
for an illustrated
description�
Turn the MIX knob to adjust the amount of Boost applied to
the Modded or Original Tube Preamp (when enabled via the
preceding Preamp Select function), from 0dB (unity gain, the
default setting) to +6dB�
