1. Introduction
Thank you for purchasing this piece of Stuart equipment. To get the best performance from the
SMP50 please read these instructions carefully before use. Before discarding the packaging check that
all parts are present and correct.
For your own safety and that of others please read and understand the safety advice given
below before using the equipment.
2. Safety advice before use
If the equipment is not used in the manner described in this manual and with accessories other than
those recommended by Stuart, the protection provided might be impaired.
Please consult the user manual in all cases where this symbol is identified on the product in
order to find out the nature of any potential hazards and any actions that must be taken to
avoid them.
This equipment is designed to operate under the following conditions:
❖ For indoor use only
❖ Use in a well ventilated area
❖ Ambient temperature range +5°C to +40°C
❖ Altitude to 2000m
❖ Relative humidity not exceeding 80%
❖ Mains supply fluctuation not exceeding 10%
❖ Over-voltage category II IEC 60364-4-443
❖ Pollution degree 2
General safety advice:
❖ Never move or carry the unit when in use or connected to the mains electricity supply.
❖ The unit should be carried using both hands with fingers under each side of the frame.
❖ The ventilation slots at the back of the sample block should not be sealed or obstructed.
Leave at least 100mm clearance.
3. General description
The SMP50 is designed to automatically measure and record the melting temperatures of crystalline
samples held within capillary tubes. Up to three tubes can be accommodated in an illuminated
chamber within an aluminium block. The tubes are monitored by a digital camera; the image of which
can be viewed on the instrument display during the melting process. The device is designed to be
independently operated using the colour touch screen allowing all operational and data management
functions to be performed without the need to attach an external computer or keyboard.
The temperature range of the device is ambient to 400°C and the heating rate is variable between
0.1°C and 20°C/minute. All of the instrument functions and menus are accessed using the colour
touch screen interface which allows fast and intuitive navigation throughout a melting point
