928 Mixing Console
E 3/6 Jumpers
Edition:
07.02.01
Remote control key With the START key the fader start can be prepared or initiated. If the
key is pressed when the fader is closed (dim backlight of the key) the
fader start command is executed as soon as the fader is opened and the
ON key is activated.
If the START key is pressed when the fader is already open and the ON
key is active, it immediately executes the fader start command.
J4 (on
Side Board)
1-2 (default) START key is active
2-3 START key is ineffective, fader start depends only
on the fader and the ON key
J3 (on
Side Board)
1-2 The START key generates start pulses
2-3 (default) The START key functions as a latching
start/stop key and enables or disables fader start
activation with the fader control
Input channel Meters The built-in LED meter can be operated with VU or PPM characteristic
and can indicate either the input signal or the signal on the direct output
(N-1).
J7
1-2 VU characteristic
2-3 (default) PPM characteristic
J5 + J6
1-2 Meter on direct (N-1) output signal
2-3 (default) Meter before EQ
Direct output The signal for the direct output can optionally be tapped before or after
the fader.
J8 + J9
1-2 (default) Direct output post-fader
2-3 Direct output pre-fader
J1 (on
Side Board)
1-2 For talkback to the Dir/N-1 output the normal
output signal is interrupted (TB signal exclusive)
2-3 (default) The talkback signal is added to the Dir/N-1 signal
