Studer 928 Service Manual

928 Mixing Console
Jumpers E 3/7
Edition:
07.02.01
3.1.3 GROUP UNIT 1.928.230
Stereo return
With the EXT/GRP key, the stereo return signal can be selected either
from an external stereo line input or from the internal pre-fader group
signal.
If in GRP position (key pressed), the signal is tapped before or after the
limiter, depending on the position of jumper J1.
J1
1-2 (default)
Before fader and limiter/compressor
2-3
After fader and limiter/compressor
Groups
If jumpers J2...J5 are not set, the bus cannot be connected to the own
group.
Do NOT set Jumper for groups
J5 1 and 2
J4 3 and 4
J3 5 and 6
J2 7 and 8
Talkback
J6
closed (default)
Slate signal replaces group signal
open
Slate signal is mixed down to the group signal
J8
closed (default)
Talkback signal replaces group signal
open
Talkback signal is mixed to the group signal
J7
1-2 (default)
On Air signal has no influence on TB
2-3
On Air signal inhibits talkback and slate
