Studer 928 Service Manual

928 Mixing Console
E 3/10 Jumpers
Edition:
07.02.01
3.1.6 STUDIO MONITOR 1.928.520
Option TB output of user keys
J1 / J2
1-2
An external signal is connected to User Output
2-3
Ground is connected to User Output
J5 / J6
1-2
Talk to all N-1 outputs
Talkback to studio speaker
J3
1-2 (default)
Red light interrupts talkback to the studio speaker
2-3
Even when red light is on, talkback to the studio
speaker is possible
J4
1-2 (default)
The talkback signal is mixed to the speaker signal
2-3
Interrupts the speaker signal during talkback
Internal/external volume control of studio speaker
J7
1-2
The volume is controlled by an external
potentiometer
2-3 (default)
The built-in speaker potentiometer is enabled
